Power supplies : 200 - 240V 50/60Hz or 100 - 120V 50/60Hz
(The power supply can be changed over with the built-in selector.)
Input power : 950VA at 230V 50Hz (PFC electronic Ballast).
Lamp :
575W metal iodide lamp.
• Cap: SFc 10 -4
• Color temperature: 6,000 K
• Luminous flux: 49,000 lm
• Average life: 1,000 h
• Hot lamp restrike.
Code L10029 HMI 575W/GS lamp
Code L10073 CSR 575W/DE lamp
Input : DMX 512
Body :
• Aluminium structure with die-cast plastic cover.
• Two side handles for transportation.
• Device locking PAN and TILT mechanisms for transportation and maintenance.
Moving body :
• Angle: PAN = 450°, TILT = 252°
• Maximum speeds: PAN = 4.0 sec. (360°) / TILT = 3.2 sec. (252°)
• Resolution: PAN = 1.76° - PAN FINE = 0.007° / TILT = 0.98° - TILT FINE = 0.004°
• Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit.
Cooling : Forced ventilation with axial fans.
Safety devices :
• Bipolar circuit breaker with thermal protection.
• Automatic break in power supply in case of overheating.
Recommended working position : Functions in any position.
CE marking : In conformity with the European Union Low Voltage Directive 73/23 and Electromagnetic Compatibility Directive 89/336.
