Components : LF 1 x 15" (38cm) long excursion Neodymium 8Ω driver.
Connectors : 2 x NL4MP SPEAKON 4 pole.
Construction : Baltic Birch Ply & textured, polyurethane black coating.
Fittings : Handles 2 Metal recessed pockets.
Flying Points : One plate connecting with external accessories.
Stand fittings : Internal Steel Stand Fitting on Top (35mm, 1 3/8") allows pole mounting for 1 PS10-R2.
SYSTEM SPECIFICATIONS LS600 with PS10 TDController-R2
Frequency Response [a] : 40 Hz - 110 Hz ±3dB.
Usable Range @-6dB [a] : 38 Hz - 120 Hz.
Sensitivity 1W @ 1m [b] : 101 dB SPL Nominal.
Nominal Peak SPL @ 1m [b] : 135 to 138 dB Peak.
Crossover Frequencies : 120 Hz Active through PS10 TD Controller-R2.
Nominal Impedance : 8 Ohms.
Recommended Amplifiers : 1000 to 2000 Watts / 8 Ohms.
SYSTEM OPERATION
Electronic Controller : The LS600 Subwoofer must be used with a Nexo Controller (PS10TD -R2, NX242, or NXAMPS).Use without a properly connected Controller will result in poor sound quality and may damage the components.
Subbass : The LS600 Subwoofer provides optional VLF extension for PS10R2 Loudspeakers. Active two-way operation with the PS10-R2 is included in the PS10TD-R2, NX242 or NXAMPS. One LS600 matches 2 x PS10-R2, additional LS600 may be used for enhanced effect.
Speaker Cables : The PS10R2 is wired 2- & 2+ on Speakon connectors, LS600 on 1- & 1+. Loop through Speakons are present on both products. Single identical cables can thus be used to loop through combinations of up to 2 x PS10R2 & 1 x LS600 in no particular order. As part of a policy of continual improvement, NEXO reserves the right to change specifications without notice.
