Robe RoboSpot MotionCamera

The RoboSpot MotionCamera is a revolutionary moving head fixture featuring an integrated HD camera remotely controlled via DMX to pan, tilt, zoom and autofocus.
Featuring a full HD camera with high light sensitivity capabilities down to 0.3 Lux illumination levels, the fixture provides a “first person view” for the followspot operator to track the performer across the stage. Video signals are instantly transferred to the RoboSpot BaseStation via a high-speed Ethernet cat5 cable.

CAMERA
  • Type: SNZ-6320
  • Resolution: 1920x1080, 16:9 Full HD (1080p) resolution support
  • Zoom:
    • 32x optical zoom
    • 16x digital zoom
  • Streaming: H.264, MPEG dual codec, Multiple streaming
  • Vision: Day & Night (ICR), WDR (120dB)
  • Minimum illumination: 0.3 Lux
CONTROL AND PROGRAMMING
  • Setting & Addressing: two-row LCD display & 4 control buttons
  • Protocols: USITT DMX-512, RDM
  • Wireless CRMX™ technology from Lumen Radio (on request)
  • DMX Protocol modes: 1
  • Control channels: 8
  • Pan/Tilt resolution: 16 bit
  • Zoom: 8 bit
MOVEMENT
  • Tilt movement: 270°
  • Pan movement: 540°
  • Movement control: Standard and Speed
  • Automatic Pan/Tilt position correction
THERMAL SPECIFICATION
  • Maximum ambient temperature: 45°C (113°F)
  • Maximum surface temperature: 55°C (131°F)
  • Minimum operating temperature: -5°C (23°F)
ELECTRICAL SPECIFICATION AND CONNECTIONS
  • Power supply: Electronic auto-ranging
  • Input voltage range: 100-240 V, 50/60 Hz
  • Power consumption: 35 W at 230V / 50 Hz
  • Power in/out connector: Neutrik powerCON TRUE1 in/out
  • DMX and RDM data in/out: Locking 5-pin XLR
  • Camera output: RJ 45
APPROVALS
  • CE Compliant
  • cETLus Compliant (pending)
RIGGING
  • Mounting positions: Horizontally or vertically
  • 1x Omega adaptor with ¼-turn quick locks
  • Universal operating position
  • Mounting points: 1 pair of ¼ -turn locking points
  • Safety cable attachment point

Galerie photos


Propriétés techniques


  • Consommation électrique: 35 W
  • Dimensions en flight-case (X1): … x … x … cm
  • Dimensions unitaires: 385 x 276 x 147 mm
  • Poids en flight-case (X1): … kg
  • Poids unitaire: 6,5 kg
