L-ACOUSTICS V-DOSC

2-way active WST® enclosure
amplified by LA4X / LA8 / LA12X

Usable bandwidth (-10 dB)

42 Hz – 20 kHz ([K3 70])

Maximum SPL1

143 dB ([K3 70])

Nominal directivity (-6 dB)

Horizontal: 70° / 110° symmetric or 90° asymmetric
vertical: depending on number of elements and array curvature

Transducers

LF: 2 × 12″ neodymium cone driver
HF: 1 × 4″ diaphragm compression driver, neodymium

Acoustical load

LF: bass-reflex, L-Vents
HF: DOSC waveguide, Panflex

Nominal impedance

LF : 8 ?
HF : 8 ?

Physical specs



Connectors

2 × 4-point speakON

Rigging and handling

Flush-fitting 4-point rigging system
2 handles
inter-enclosure angles: 0.25°, 1°, 2°, 3°, 4°, 5°, 7.5° or 10°

Weight (net)

43 kg / 95 lb

Cabinet

Premium grade Baltic birch plywood

Front

Coated steel grill
acoustically neutral 3D fabric

Rigging components

High grade steel with anti-corrosion coating

Finish

Dark grey brown Pantone 426 C

IP

IP55



Galerie photos

L-ACOUSTICS V-DOSC
L-ACOUSTICS V-DOSC
L-ACOUSTICS V-DOSC
L-ACOUSTICS V-DOSC
L-ACOUSTICS V-DOSC
L-ACOUSTICS V-DOSC

Propriétés techniques


  • Dimensions unitaires: 1300*434*565mm
  • Poids: 108kg
